Select galaxies for shear measurement:
Once you have a shape catalogue you need to decide which galaxies to use in your analysis. With nearly all shape measurement methods this selection is rather ‘black magic’ and your choice usually has a significant impact on your results. The exception to this is the Lensfit method which outputs a probability distribution of the shear for each galaxy.
For KSB your selection should be based on the following
•Remove all galaxies that are within a mask
•Remove galaxies which have a size close to the PSF size. These galaxies are usually hard to completely remove the PSF distortion from. I find rg>1.15 r_star works well
•Remove low signal-to-noise galaxies which are hard to measure shapes from. I find S/N>10 works well
•Remove really noisy shape measurements. I find |γ| < 1 works well.
The above selection criteria are used in gal_correct to write out the average shear in the catalogue.
How should you choose your selection criteria?
If you have wide-field data you know that on average <γ> = 0. This should be true for all galaxy sizes, all magnitudes and all S/N. gal_select.f90 bins and averages your shape catalogue by size, magnitude and S/N. You can then identify “problem” galaxies which are biasing your shear measurement.
Should you fit Pgamma?
Many KSB users do fit Pgamma with a polynomial to reduce noise in the final shear catalogue. My experience is that this fit biases your result, however I include the ability to do this fit with the gal_select -fit 1 option.
The resulting simple final shear catalogue
The output file is very simple
# 1 x SExtractor x
# 2 y SExtractor y
# 3 g1 KSBf90 output reduced shear_1
# 4 g2 KSBf90 output reduced shear_2
Running gal_select.f90 from the command line:
gal_select.a -in shape.cat -param KSBf90.param -fit 0 -nbins 10 -out finalshear.cat
-in : Your SExtractor catalogue with KSB shape parameters appended output by gal_correct
-param: The name and location of your parameter file
-fit : Do you want to fit Pgamma with a polynomial? Yes - fit 1, No -fit 0
-out: The output of this code; your final selected shear catalogue
